Matrix Switches

Matrix switches deliver world-class distribution of your source material to every room in a residential installation. 4K Ultra HD products feature HDCP 2.2 compliancy, making them compatible with current and future 4K content and enabling homeowners to enjoy copy-protected 4K content on every TV throughout the house.

FEATURES

  • Control each zone’s audio or video settings individually, ensuring the best match between media source and destination playback.
  • Leaf Ultra HD AV Matrix Switches let you distribute IR, RS232, and Ethernet signals to your media end points, bringing device control and high-speed networking right where you need it.
  • Distributes HDMI sources to video display locations with full HD clarity.
  • All video sources connect to the HDMI Matrix Switch in a central location, tucked away and out of sight (excludes Audio Matrix Switch).

8X8 HDMI
MATRIX SWITCH

C4-HDBTEB-B
Spec Sheet

Distributes eight HDMI sources to eight video display locations with full HD clarity. All video sources connect to the HDMI Matrix Switch in a central location, tucked away and out of sight. As an added benefit, wiring and clutter are reduced substantially with HDBaseT distribution of HD video, audio, Ethernet and control over a single Cat-5e/6 cable to each TV location.

AUDIO
MATRIX SWITCH

C4-16ZAMSV3-B
Spec Sheet

Enables up to 16 stereo audio sources to simultaneously play to 16 audio outputs. Each output zone can be enhanced with individual gain control, as well as independent bass and treble control. Ideal for use with Control4 amplifiers when more than eight audio sources and/or audio zones are required.

CONTROL4® 4K ULTRA HD 10X10 AV MATRIX SWITCH

C4-LU1082
Spec Sheet

Distributes any of 10 Ultra HD video sources to any of 10 Ultra HD video displays by using either direct HDMI or the optional PoH-powered HDBaseT receivers (which also carry IR, serial and Ethernet signals).

CONTROL4® 4K ULTRA HD 8X8 AV MATRIX SWITCH

C4-LU862
Spec Sheet

Distributes eight HDMI sources to eight video display locations with full HD clarity. All video sources connect to the HDMI Matrix Switch in a central location, tucked away and out of sight. As an added benefit, wiring and clutter are reduced substantially with HDBaseT distribution of HD video, audio, Ethernet and control over a single Cat-5e/6 cable to each TV location.

CONTROL4® 4K ULTRA HD 6X6 AV MATRIX SWITCH

C4-LU642
Spec Sheet

Distributes any of six Ultra HD video sources to any of six Ultra HD video displays by using either direct HDMI or the optional PoH-powered HDBaseT receivers (which also carry IR, serial, and Ethernet signals).

CONTROL4® 4K ULTRA HD 6X6 MATRIX KIT

C4-LU642L-KIT
Spec Sheet

Distributes any of six Ultra HD video sources to any of six Ultra HD video displays. Includes four HDBaseT Receivers to break out HDMI, stereo, IR, and Ethernet signals.

CONTROL4® 4K ULTRA HD 10X10 AV MATRIX SWITCH WITH AUDIO DOWNMIXING

C4-LU1082D
Spec Sheet

Distributes any of 10 Ultra HD video sources to any of 10 Ultra HD video displays by using either direct HDMI or the optional PoH-powered HDBaseT receivers (which also carry IR, serial and Ethernet signals). Downmixes multichannel audio from any of the HDMI inputs to the HDMI, HDBaseT, and stereo outputs to hear video sources in any room.

CONTROL4® 4K ULTRA HD 8X8 AV MATRIX SWITCH WITH AUDIO DOWNMIXING

C4-LU862D
Spec Sheet

Distributes any of eight Ultra HD video sources to any of eight Ultra HD video displays by using either direct HDMI or the optional PoH-powered HDBaseT receivers (which also carry IR, serial, and Ethernet signals). Downmixes multichannel audio from any of the HDMI inputs to the HDMI, HDBaseT, and stereo outputs to hear video sources in any room.

CONTROL4® 4K ULTRA HD 6X6 AV MATRIX SWITCH WITH AUDIO DOWNMIXING

C4-LU642D
Spec Sheet

Distributes any of six Ultra HD video sources to any of six Ultra HD video displays by using either direct HDMI or the optional PoH-powered HDBaseT receivers (which also carry IR, serial, and Ethernet signals). Downmixes multichannel audio from any of the HDMI inputs to the HDMI, HDBaseT, and stereo outputs to hear video sources in any room.
